JUNXY Series Constant Current Battery Load Bank

☰
×
Why does battery bank need preventative testing?

There are three main reasons to do preventative test battery bank systems:

  • To make sure that the supported equipment with battery bank are adequately backedup
  • To prevent unexpected failures by tracking the battery bank health(deterioration trend)
  • To forewarn/predict battery bank death(Each battery SOH--battery state of health)
What battery bank test & maintenance solutions does JUNXY ENERGY provides?

Battery bank regularly preventative maintenance checks to make sure your battery bank backup power systems are WELL prepared when you need them most. JUNXY provides whole preventative test maintenance power solutions for your battery bank power system to test battery temperature, voltage, charge & discharge current, connector resistance, battery resistance and battery conductance and battery string capacity, our preventative maintenance programs include:

  1. Battery regenerator
  2. Battery monitoring system
  3. Battery intelligent charger
  4. Battery charger-discharger and monitor
  5. Battery resistance & conductance tester
  6. Battery load bank capacity discharger with cell voltage monitoring
JUNXY Battery Load Bank---

JUNXY Constant Current Loading Battery Load Bank, Real Time Battery String & Cell Voltage Monitoring (BVM)

JUNXY Series Constant Current DC Load Bank

JUNXY series constant current battery load bank & DC load banks are designed for DC source loading test, especially for battery bank capacity/Ah check & maintenance. The battery load bank discharger loading current is constant within the specified voltage range. Battery Load bank constant load current adjustable & controlled by MOSFET, use the PTC ceramic resistors for load power consuming.

Battery Load Bank Capacity Discharger BVM is used to test all batteries voltage during discharge (OPTIONAL)

Features
  • Battery Load bank adopting the PTC ceramic resistor to avoid red heating phenomenon, safe loading test process.
  • Wireless communication between BVM and battery load bank main unit, no need troublesome wiring for load bank discharge wiring process (OPTIONAL).
  • BVM testing & monitoring all batteries voltage during battery load bank loading test (OPTIONAL).
  • Battery Load Bank PC software upload test data from USB, all test details available by the software.
  • Apply the intelligent one-chip computer ARM for battery load bank capacity discharger tester loading control
  • Multiple adjustable threshold to stop battery load bank discharge process automatically:
  1. Battery(Cell) voltage
  2. Battery bank string voltage
  3. Discharge capacity
  4. Discharge time.
  • Real time monitoring battery bank during battery load bank testing: battery string voltage, each cell voltage, discharge current, monitoring time, discharge capacity etc.
  • One BVM could monitor up to 12pcs battery during battery bank capacity test(OPTIONAL): 12pcs.
  • Battery Load Bank Discharging mode: Battery load bank constant current discharge the battery bank
  • Battery load bank Protections: over current protection, over voltage protection, reverse polarity protection with LCD displaying and buzzer alarm for the battery load bank protection.
  • 2 or more battery load bank Parallel load bank discharging for higher discharge current
